Thuis /Producten/Digitale loadcel/Chinese Cheap Steel Load Cell Pressure Sensor For Digital Weight Scales (ET-1A) ET-1A

Chinese Cheap Steel Load Cell Pressure Sensor For Digital Weight Scales (ET-1A) ET-1A

1.0 Sets
MOQ
Chinese Cheap Steel Load Cell Pressure Sensor For Digital Weight Scales (ET-1A) ET-1A
Kenmerken Galerij Productomschrijving Verzoek om een Citaat
Kenmerken
Specificaties
Model Number: ET-1A
Power Supply: 10V
Display Type: LCD
Rated Output: 1.20±0.10
Nonlinearity: ±0.02%FS
Hysteresis: ±0.02%FS
Repeatability: ±0.01%FS
Creep(30 minutes): ±0.02%FS
Zero balance: ±1.00%FS
Input resistance: 385±15
Output resistance: 350±5
Safe overload: 300%FS
Basis informatie
Model Number: ET-1A
Betalen & Verzenden Algemene voorwaarden
Packaging Details: carton
Supply Ability: 35000 Set/Sets per Month
Productomschrijving

Specification

Rated Output

1.20±0.10

Nonlinearity

±0.02%FS

Hysteresis

±0.02%FS

Repeatability

±0.01%FS

Creep(30 minutes)

±0.02%FS/10°C

Zero balance

±1.00%FS

Temperature effect on zero

±0.02%FS/10°C

Temperature effect on output

±0.02%FS/10°C

Input resistance(Ω)

385±15

Output resistance(Ω)

350±5

Insulation resistance

≥5000MΩ

Excitation voltage

10V(DC/AC)

Compensated temperature range

-10~+50°C

Operating temperature range

-20~+60°C

Safe overload

300%FS

Cable

Φ4X0.5 M(1M)

Cable color code

Input: red+ black-

Output: green+ white-
